Anotace knihy

The work focuses on the study, design and§implementation of a C band Microwave oscillator using§coaxial resonators, for the transceiver used in wave§radar. It involves a literature study discussing§different aspects of microwave oscillators, mainly§the shielding of the oscillators, frequency pulling§due to load and supply pulling, tuning range and the§temperature performance of the oscillator. The study§of the shielding resulted in proposing a high quality§metallic shield with high elastic modulus, high§strength and high density, as the wave radar will be§a stationary, standalone system and the weight of the§shield is not a limiting factor. The metallic shield§provides better EMI and EMP performance than the§carbon ferrites. The characterization of the§resonator is critical as a small mistake pulled the§frequency about 300 MHz. This can be achieved by§careful design and measuring the resonator test§circuits for one port. The tuning range of the§oscillator is important as the temperature, bias, and§load mismatches can increase or decrease the§frequency of the oscillator. The varactor in§combination with a capacitor increases the tuning§range to about 10 times.

Parametry knihy

Zařazení knihy Knihy v angličtině Technology, engineering, agriculture Energy technology & engineering Electrical engineering

• Plný název: Microwave Oscillator Design
• Podnázev: Design, Implementation, Simulations and Results
• Autor: Maaz Rasheed
• Jazyk: Angličtina
• Vazba: Brožovaná
• Počet stran: 68
• EAN: 9783639162387
• ISBN: 3639162382
• ID: 06824656
• Nakladatelství: VDM Verlag
• Hmotnost: 113 g
• Rozměry: 229 × 152 × 4 mm
• Datum vydání: 10. July 2009
